Programming your Zeal60 RGB PCB December 15 2016

Congratulations on purchasing a Zeal60 RGB PCB! Here are a few important notes that you should read before assembling the board.

If instructions below are not followed, some RGB LEDs will not light up and a few select LEDs will be emitting the wrong colour/not in sync

  • There are a few small jumper pads next to their corresponding RGB LEDs that need to be bridged, based on the layout you plan on assembling the board with. For example, if going for the standard "Poker" style winkey layout with 6.25 spacebar, please bridge "JC0", "JC6", "JC16A", "JD7", "JD5", "JB14", "JB4" as seen in the picture below.   To make the bridging process easier, solder two small blobs onto the jumper pads first. Then once the solder has cooled down, use your chisel tip and heat up both blobs at the same time. Press down, then drag off the jumper pads onto the bare PCB. This whole process shouldn't take more than 3 seconds, and if done right, the blobs will merge together. This needed to be done due to the many keyboard layouts the Zeal60 supports.
  • Please note that for ISO layouts, the ISO_Enter switch bottom will need to be converted into “plate mount” style due to the nearby SMD LEDs taking up space where the PCB mount pins would have been.
  • Once the appropriate pads are bridged, the proper .bat layout must be flashed for the proper LEDs to light up.

JB4: Normal Backspace
JB4A: Split Backspace (HHKB style)

JB14: |\  (or HHKB Backspace)
JB14A: ISO Enter

JD5: ANSI Enter
JD5A: ISO key

JD7: Long 2.75 right Shift
JD7A: Short 1.75 right Shift

JC0: 6.25U Spacebar
JC0A: 7U Spacebar

JC6: 6.25U Spacebar stabilizer
JC6A: 7U Spacebar stabilizer

JC16: Short 1.25 ISO left shift
JC16A: Long ANSI 2.25 left shift

There are a few ANSI/ISO/Spacebar/FN LEDs that will be on regardless of jumper configuration. Those lights can be turned off in firmware.

Download the Firmware/Software HERE. This is V0.5 of the firmware/keymapper. Firmware source code published on Wilba's GitHub (QMK Fork)

Before proceeding, please make sure you have FLIP installed for easy flashing for the first .hex file. Chances are, this isn't the first time you've flashed a board, so you should have the proper drivers installed for the ATmega32u4. If it's your first time, worry not. Installing FLIP is pretty easy. Just follow these few steps here.
Press on the golden button between "A" and "S" to set your PCB to bootloader mode. In the future, if you're looking to flash the hex again, Space+ESC while plugging in will reset the board and set it to bootloader mode.
Please flash "zeal60_default.hex" onto your PCBs in order to access the .bat files. The pre-loaded hex file on your Zeal60 is only a test hex to check that all LEDs work and will not work with the .bat files by design.
Once flashed, pick a layout you would like the Zeal60 to use. Clicking on the desired .bat file layout and your PCB will be programmed accordingly without compiling your own .hex.
Depending on the layout, Fn1 and Fn2 are assigned to right Win and Menu keys, or to split-shift "Fn" key and right Win key.
The default backlight controls are on layer 3, which is (by default) enabled by holding down Fn1 and Fn2
Layer3 keys:

1 / 2 - change effect
 - All Off
 - Solid Color 1
 - Alphas/Mods Color 1/2
 - Gradient Vertical Color 1/2
 - Cycle All
 - Cycle Horizontal
 - Cycle Vertical
 - Custom Key Colors

3 / 4 - color 1 hue -/+
E / R - color 1 sat -/+
5 / 6 - color 2 hue -/+
T / Y - color 2 sat -/+
- / + - brightness -/+


When the zeal60 firmware is programmed, holding Space + Esc down while powering on (i.e. connecting USB to keyboard) will reset ALL the stored settings (keymaps, backlight, etc.) and start the bootloader so it is ready for firmware programming with Flip. If you only want to reset the stored settings, disconnect/connect USB and the firmware is restarted.

Please read "readme.txt" for further instructions & details.


Dec 15, 2016
V0.0 Release.

December 30, 2016
Updated to V0.1 firmware with readme.txt. Added reactive lighting.

January 6, 2017
Updated to V0.2 firmware with toggle/hold via LT(layer, kc) command, tweaked stabilizer LEDs during reactive lighting.

January 9, 2017
Updated to V0.3 firmware. Added option to disable backlight when USB suspended / disable backlight after inactivity timeout.
Reactive mode added to all color cycle effects.

January 24, 2017
Updated to V0.4 firmware.
- More backlight effects and some fixes to existing ones. Color blending between two colors now uses saturation as well as hue.
- Set all backlight parameters via the .bat file, so you don't need to set them via the keyboard.
- Caps Lock/Fn layer indicators. Make one or all keys change to a color when Caps Lock is on, or you have a Fn layer active.

January 25, 2017
Updated to V0.5 firmware.
- Fixed bugs in previous release
- Added "zeal60_mousekey.hex" for people that want QMK's "mousekey" functionality
